Foil Barcode Labels

Photo Anodized Foil Labels

Product Features:

Made of .003” thick matte anodized aluminum
Photographically reproduced black copy, logos and barcodes ensure accurate and reliable reads
Anodizing process protects black copy, logos and barcodes from chemicals, abrasion and high temperatures
Conforms easily to radius surfaces
One Color & Full Color Print Otions
Adhesives specially matched to surface for maximum adhesion

Customize This Label

Free Shipping

Product Category:

Foil

Metal

Typical Applications:

Returnable Containers

Product tabs

Description

Durability, reliability and versatility – all in one product! Foil Barcode Labels are ideal for customers who require a flexible label that will conform to most surfaces, yet need a product that will withstand harsh conditions including chemicals, abrasion, solvents, and high temperatures.

Foil Barcode Labels are available with or without a barcode. Black copy, logos and bar codes are photographically reproduced for maximum clarity and detail and then sealed within the anodic layer of the aluminum – ensuring accurate and reliable reads for years to come. Optional second colors are screen printed.

This product is just as effective in the office of a manufacturing plant as it is on the production floor. Uses and applications for this product are limited only by the customer’s imagination . From tool control to calibration to original equipment identification, Foil Barcode Labels are more than up to the challenge.

Product Information

Material	.003" thick matte anodized aluminum
Attachment Method	.002" thick acrylic adhesive that has a very high peel strength and provides excellent resistance to heat and chemicals
Environment	Mild, moderate and extreme. Resists extreme abrasions, solvents and temperatures
Production Time	5 work days (Black-Type, Black-Designed) 10 work days (Color-Designed)

Durability Score
Chemical	Abrasion	Heat	UV/Outdoor	Score Avg.
3	3	3	4	3.25

Technical Specs

Product Literature
Product Sheet	Foil Barcode Product Sheet
Market Sheet	OEM Market Sheet
Other Literature	Label Products For Returnable Containers

Specifications Data:

Material	.003” thick matte anodized aluminum
Barcodes	All alphanumeric bar codes are photo imaged with a human-readable equivalent. Guaranteed no skips in sequence. Code 39 with 2.7 to 9.4 characters per inch (CPI) is standard. Other bar code symbologies including Code 128, I 2 of 5, 2D DataMatrix and QR Code.
Label Copy	The printed label copy may include block type, stylized type, logos or other designs. All black copy is produced photographically. Colors other than black are screen printed.
Colors	Choose black only or one of our standard colors (red, blue, green, or yellow) for block style type, stylized type, logos or other designs. Due to the contrast needed for the bar code scanner, all bar codes are black.
Finish	All black copy and bar codes are sealed in an anodic layer to resist defacing, abrasion, and environmental conditions.
Adhesive	Pressure-sensitive acrylic adhesive (MC78), .002” thick supported by a liner. Very high peel strength that provides excellent resistance to heat and chemicals. Will withstand temperatures from -40°F to 300°F (intermittent). Shelf life of 24 months when stored at 72°F (22°C) and 50% relative humidity.
Packaging	Shipped in peel-off strips for easy removal. Both cartons and trays are clearly marked to indicate serial numbers of contents. Pressure-sensitive adhesive orders are shipped with cleaner and application instructions.
Shipment	5 work days (Black-Type, Black-Designed), 8 work days (2 Color-Designed), 10 work days (3+ Color- Designed)

Foil Barcode Labels Pricing / price per tag at qty

	<300	300	500	1000	3000	5000	7000	>10000
1.25" x .5"	$3.27	$1.57	$1.14	$0.65	$0.35	$0.28	$0.24	$0.22
1.5" x .75"	$3.27	$1.57	$1.29	$0.80	$0.53	$0.45	$0.42	$0.39
1.75" x .5"	$3.27	$1.57	$1.22	$0.73	$0.45	$0.38	$0.34	$0.31
2" x .625"	$3.27	$1.57	$1.28	$0.77	$0.50	$0.42	$0.39	$0.36
2" x .75"	$3.27	$1.57	$1.34	$0.83	$0.56	$0.49	$0.45	$0.42	$0.00
2" x 1"	$3.27	$1.57	$1.42	$0.92	$0.66	$0.59	$0.56	$0.52
3" x 1"	$3.12	$1.50	$1.42	$1.08	$0.85	$0.80	$0.78	$0.77

Foil Barcode Labels Color Pricing / price per tag at qty

	<300	300	500	1000	3000	5000	7000	>10000
1.25" x .5"	$4.91	$2.25	$1.71	$0.94	$0.46	$0.35	$0.30	$0.26
1.5" x .75"	$4.91	$2.25	$1.80	$1.03	$0.59	$0.48	$0.44	$0.40
1.75" x .5"	$4.91	$2.25	$1.80	$1.03	$0.56	$0.45	$0.40	$0.35
2" x .625"	$4.91	$2.25	$1.86	$1.07	$0.61	$0.49	$0.45	$0.40
2" x .75"	$4.91	$2.25	$1.93	$1.14	$0.68	$0.26	$0.51	$0.46
2" x 1"	$4.91	$2.25	$2.02	$1.24	$0.79	$0.67	$0.62	$0.57
3" x 1"	$4.68	$2.15	$2.20	$1.41	$0.98	$0.86	$0.81	$0.75
